Periodically the capacitive stylus tip may need to be replaced. There are two styles of removable stylus tips.

●

Style “A” - To remove, unthread the tip counterclockwise. To install a new stylus tip, thread it on clockwise until seated.

●

Style “B” - To remove, unthread the collar counterclockwise. To install a new stylus tip, remove the old tip from the shaft and install a new tip, then thread the collar on clockwise until seated.

Stylus tips are available as optional equipment (contact your sales representative to order).

Do not overtighten the stylus tip.

Replacing stylus tip - (Style A)

Replacing stylus tip - (Style B)
