MODIS Edge

Model: EEMS341W

Say hello to confidence with the MODIS Edge from Snap-on - a complete vehicle diagnostic platform delivering advanced features plus the speed and performance you expect.

A combo scanner and scope/graphing meter with exclusive SureTrack™ Expert Information and integrated Technical Service Bulletins, it is slim, light, fast and strong.

Booting in five seconds and sporting a big eight-inch display, find new Instant ID and quick links to common procedures to get you right down to business.

Exclusive Guided Component Tests show how to test, where to connect and what to look for to eliminate guesswork.

A new Vehicle System Report offers Global OBD-II Code and Readiness Monitor results for available systems delivering convincing estimates for greater customer confidence.

MODIS Edge Diagnostic Scan Tool | Snap-on

Open AllClose All

Specifications

*Snap-on reserves the right to make changes to specifications without notice and without making changes retroactively.

Access to Intelligent DiagnositcsNot available on MODIS EdgeBatteryRemovable, Rechargeable, Lithium-ion batteryBoot up SpeedLess than 10 second boot upDepth1.6in (40.3mm)Display resolution800px x 480pxDisplay size8in (203mm)Display typeResistive, daylight-readable LCD touchscreen, colorHeight6.3in (160mm)Lab Scope / Meter2-channelBandwidth 3MHz bandwidthSample Rate: Up to 6 million samples/secScale range 0-100mV to 0-400VSweep rate 1 second to 5 minutesSweep rate as fast as 50 secondsLive Data GraphingSelective display of 1, 2 or 4 graphsNavigation4-way keypadTouchscreenOBD-IIAll 10 modes of Global OBD-IIOperating SystemEmbedded SMX®Scan ModuleIntegratedUSB PortPC connectivityWeight2.6lb (1.18kg)Width11.1in (281mm)Wi-FiWi-Fi Capable

Software

New Coverage Highlights

Transfer Case Special Functions including: Automatic Clutch Calibration, High/Low Range Position Sensor Replacement, Transfer Case Oil Replacement

2017+ Range Rover® & Range Rover Sport® added2025 Code Scan & Clear - All MakesAlfa Romeo® Stelvio® 2017+ Particle Matter Replacement Special Function

Audi® A3 2012-2020 1.4L Petrol, Audi® A6® 1997-20052.4L Petrol, Audi® A6 2014-2018 3.0L Diesel

Audi® Guided Component Tests Added for:BMW® 2015-2019 F30 (3-Series) 330e – High Voltage Battery Health Check

All affected models Ignition Rumble Misfire Reset Special Function added to the Engine Module

Citroen® 2013-2031

2018-2024 Berlingo 1.5L Diesel

Citroen® Guided Component Tests Added for:Dacia® 2023+ Jogger® 1.6L Hybrid Engine addedEV and ADAS coverage included as Snap-on standard.Fiat® Ducato® 2019 AdBlue ECU added with Codes, Data. Special Functions & Functional Tests

Kuga® 2019-2024 1.5L Diesel, Kuga® 2019-2014 1.5L Petrol, Mondeo® 2001-2007 2.5L Petrol, Transit Connect® 2005-2014 1.8L Diesel

Ford® Guided Componenet Tests Added for:

2021+ All Affected Models: Special Functions added to the ABS module to replace the ESC Variant Coding

Hyundai® Special Functions Added:

2020+ All affected Models: Selective Catalytic Reduction Special Functions and Reset added

Kia® Special Functions Added:

A200® 2018-2024 1.3L Petrol, B180® 2005-2011 2.0L Diesel, E220® 2016-2024 2.0L Diesel, E350® 2004-2010 3.5L Petrol, C230® 2002-2008 1.8L Petrol

Mercedes-Benz® Guided Componenet Tests added for:Mercedes-Benz® New Transmission Variants added to all models®

Added to R52® 2000-2006

MINI® Electrohydraulic Power Steering Control Module

Customisation and Write Learned Values for Multi Around Vision System

Mitsubishi® 2017+ Outlander L200®, Eclipse Cross®

BMW®, Citroen®, DACIA®, Ford®, Fuso®, Honda®, Iveco®, Jaguar®, Mercedes-Benz®, MINI®, Mitsubishi®, Vauxhall®/Opel®, Peugeot®, Renault®, Suzuki®

New Models Including

2013-2019 X-Trail® including: Adaptive Frontal Lighting System, System Object Detection, Chassis Control

Nissan® New Systems added to:

2013-2021 Qashqai® 1.3L Dig Turbo added Special Functions including: Engine Adaptive, Oil Change for Oxidation, Oil for Dilution, GPF Filter Regeneration

Nissan® Special Functions Added for:Peugeot® 2013-2022 All Affected Models: Ignition Rumble Misfire Reset Special Function added to the Engine ModulePeugeot® 5008® 2017+ Crash Data Reactivation Special Function added to the BSI

Captur® date ranging from 2013-2024 1.5L Diesel & Espace® 2015-2024 1.6L Diesel

Renault® Guided Componenent Tests Added for:Seat® 2022+ Leon® New 2.0L TSI Engine added

2013-2021 Octavia® 2.0L Diesel

Skoda® Guided Component Tests added for:Subaru® 2004-2010 Justy® Electro-mechanical Power Steering and Immobiliser System addedSubaru® 2020+ Outback® Electronic Brake Booster System addedSuzuki® 2022+ All Affected Models: Special Function Verification Test for Brake Pipes and Hydraulic Unit added to the ABS Module

Guided Component Tests for the Model S 2012-2022 and Model X 2015-2022 include: ABS Module, Brake Fluid Level Switch, Brake Pedal Switch, Electric Brake Booster, Electronic Parking Brake Actuator, iBoost Pedal Sensor, Wheel Speed Sensor

Tesla® Guided Componenet Tests added for:Toyota® Proace® 2016+ Diesel Particulate Filter Resets Special Function and additional DataVauxhall® Updated Core Systems- Engine, Transmission, ABS and Airbag to: 2016+ Crossland®, 2016-2021 Grandland X®

Activate Fuel Pump, Adapt DPF Adaptation Values, Adapt Injector Quantity Values, Diesel Particle Filter, Reset Engine Regulation Adaption Values

Volkswagen® 2010-2018 Touareg® 4.2L TDI engine Special Functions include:

Vehicle Gateway Module, Lounge Console Power Module, Accessory’s Gateway Unit, Telematics and Connectivity Antenna Module , Exterior Sound Module Reverse for Hybrid vehicles

Volvo® XC90®2015+ added Sub Systems, Codes, Data and applicable functional tests including:New Features and Enhancements

Visit snapon.com/securitylink/uk for details

NEW Mercedes-Benz® CeBAS Secure Gateway access added!

Toggle between English and 7 different languages on Snap-on Cloud and Altus Drive

New Snap-on® Cloud multilingual supportSoftware OptionsOutright PurchaseSubscription

Features

SureTrack - recognised in 2019 with a Queen's Award for Enterprise in the Innovation category - brings together a unique combination of intelligence and expertise to help auto repair technicians of any experience level increase accuracy and efficiency from diagnosis to a completed repair.

The industry's most comprehensive source of expert knowledge for professional technicians, SureTrack combines real-world insights with repair time-savers and detailed parts replacement records.

Build a diagnostic strategy with Real Fixes, Top Repairs, Causes and Fixes and more to reduce diagnostic time and increase accuracy.

Find out more about SureTrack and the exclusive benefits it can bring to your workshop.

SureTrack expert information and verified parts replacement records for a confident diagnosis

Snap-on diagnostic tools are known the world over for great performance, rock-solid construction and intuitive design, along with instant access to online and in person training solutions.

But what makes them the best in the industry is what we put into them, both when they're built and over the life of every tool.

Ensuring your software is up to date means that your tool is always ready for the next job that comes into the garage.

Take a look at what's new in the latest diagnostic software upgrade from Snap-on and find out everything it can do for you and your business, while also discovering how you can save money with a Software Subscription Plan.

In-depth diagnostic software and subscription plans

Offers a complete overview of all available system results and Readiness Monitors that can be printed and personalised to your garage and customers' vehicles

Vehicle System ReportExclusive Guided Component Tests show how to test, where to connect and what results to look forQuick access to common procedures, oil specs and service interval resetsUp to eight live data parameters displayed on-screen at one time in digital formatExtended wireless range assists in triage functions and bay productivityIntegrated full-function scan tool and high-speed scope/graphing meterFinger-driven eight-inch color touchscreen and four-way thumb pad for quick navigationOEM-specific scanner coverage

Use powerful functional tests while viewing live data parameters on-screen

Unique 'cause and effect' diagnostics make it easy to see the root cause of problems

Resource Centre

Snap-on MODIS Edge User Manual
